型号 Series Model | 步距角 Step Angel | 机身长 Motor Length(mm) | 静力矩 Holding Torque(g.cm) | 引线数 Lead Wire | 相电流 Rated Current (A) | 相电阻 Phase Resistance | 相电感 Phase Inductance (mH) | 转动惯量Rotor Inertia(g.cm^2) | 重量 Motor Weight (kg) |
(No) | (Ω) | ||||||||
28BYGH-01 | 1.8 | 32 | 600 | 4 | 0.67 | 5.8 | 3.2 | 9*10-7 | 0.11 |
28BYGH-02 | 1.8 | 32 | 430 | 6 | 0.95 | 2.8 | 1 | 9*10-7 | 0.11 |
28BYGH-03 | 1.8 | 45 | 950 | 4 | 0.67 | 6.8 | 4.9 | 12*10-7 | 0.14 |
28BYGH-04 | 1.8 | 45 | 750 | 6 | 0.95 | 3.4 | 1.2 | 12*10-7 | 0.14 |
28BYGH-05 | 1.8 | 51 | 1200 | 4 | 0.67 | 12 | 7.2 | 18*10-7 | 0.2 |
28BYGH-06 | 1.8 | 51 | 900 | 6 | 0.95 | 4 | 1.1 | 18*10-7 | 0.2 |
